PRODUCT HIGHLIGHTS
VERITON X4610G DESKTOP (sandy bridge)
- Intel Corei3 2120 3.30GHZ
- Intel® Q65 Express Chipset
- Intel® HD Graphics support
- 2GB DDR3 1333MHZ
- 500GB SATA3 7200RPM
- 16X Super Multi Drive
- PCI-E 2.0 x16 slot, PCI-E 2.0 x1 slot
- (RJ45) Port, VGA Port, DVI-D
- Four USB 2.0 ports, Six USB 2.0 ports
- Gigabit LAN, NO LCD
- 220W, USB KB & USB Mouse
TM4750z-B962G50Mnss NOTEBOOK (sandy bridge)
- Intel Pentium Dual Core B960
- 2.2GHz, 2MB L3, 1333MHz FSB
- Intel HM65 Express Chipset
- 2GB DDRIII Memory
- 500GB 5400rpm Hard Disk
- Intel Graphics
- 14inches HD 1366 x 768 pixel
- 8X DVD-Super Multi Drive
- VGA port, 3x USB 2.0 port
- Gigabit LAN (WOL), BLUETOOTH
TM4750-2332G50Mnss NOTEBOOK (sandy bridge)
- Intel Core i3 2330M 2.2GHz
- 3MB L3, 1333MHZ FSB
- Intel HM65 Express chipset
- 2GB DDRIII 1066MHz Memory
- 500GB 5400rpm Hard Disk
- Intel HD Graphics
- 14inches HD 1366x768 pixel
- 8x DVD-Super Multi Drive
- 3x USB 2.0 port, HDMI w/ HDCP
- Gigabit LAN, BLUETOOTH, VGA port
Edifier R2000T
Audio Input: P/C/MP3/CD/DVD 3.5mm to RCA inputs
Total Power Input: 30W x 2 RMS
Edifier S2000V
Audio Input: RCA
Total Power Output: 60W x 2 RMS
Edifier Studio 6
Audio Input: Dual RCA input(RCA-RCA and RCA to AUX)
Total Power Output: 30W x 2 +
32W x 2 RMS
NEW! W316R
| Hardware Features | ||
| Standards | 802.11n, 802.11g, 802.11b, 802.3, 802.3u | |
| Band | 2.4Ghz | |
| Wireless Rate | 150Mbps | |
| Interface & Speed | 1 10/100Mbps auto-negotiation Ethernet WAN Port 4 10/100Mbps auto-negotiation Ethernet LAN Ports |
|
| Button | WPS/Reset | |
| LED | POWER/SYS/WPS/WLAN/LAN/WAN | |
| Antenna | 5dBi non-detachable antenna | |
| Power | 170-240 V 9V==600mA |
|
| Dimensions (LxWxH,mm) | 159.6mm×102.2mm×31mm | |
| Wireless Features | ||
| Basic Features | Channel | 11 channels |
| Channel Width | 20Mhz, 40Mhz | |
| Transmit Power | b Mode： 1, 2, 5.5, 11Mbps : 17dbm， +0.5dbm/-0.5dbm g Mode： 6, 9Mbps : 16dbm，+0.5dbm, -0.5dbm 12, 18Mbps : 15.5dbm，+0.5dbm, -0.5dbm 24, 36Mbps : 15dbm，+0.5dbm, -0.5dbm 48, 54Mbps : 15dbm，+0.5dbm, -0.5dbm n Mode：(20/40M Mode) MCS0, 1_：7.2/15, 14.4/30 Mbps ：16dbm，+0.5dbm, -0.5dbm MCS2, 3_：21.7/45, 28.9/60 Mbps ：15.5dbm，+0.5dbm, -0.5dbm MCS4, 5_：43.3/90, 57.8/120 Mbps ：15dbm，+0.5dbm, -0.5dbm MCS6, 7_：65/135, 72.2/150 Mbps ：15dbm，+0.5dbm, -0.5dbm |
|
| Working Modes | Wirelss AP; WDS; Wireless Router | |
| Wireless Security | WPA-PSK,WPA2-PSK,WPA-PSK&WPA2-PSK | |
| Software Features | ||
| Internet Connection Type | Dynamic/Static/PPPoE/PPTP/L2TP | |
| DHCP | Built-in DHCP server | |
| Security | Port/URL/MAC address filter | |
| Bandwidth Control | WMM | |
| DDNS | Yes | |
| Others | ||
| Operating Enviroment | Operating Temperature | 0℃ ~ 40℃ |
| Storage Temperature | -30oC ~ 70oC | |
| Operating Humidity | 10% ~ 90% RH non-condensing | |
| Storage Humidity | 10% ~ 90% RH non-condensing | |
| Minimum System Requirement | Computer with: Internet Explorer 5.5 or Firefox 1.0 Higher CD Drive Network Adapter |
|
| Package Contents | W316R Wireless-N Broadband Router Power Adapter Quick Installation Guide One Software CD (User Guide and Setup Wizard included) |
|
| Certificates | FCC CE RoHS | |
